Microcracks mean wobbly screws

Orthodontists often use miniscrews as temporary anchorage devices to attach wires used to realign teeth. Miniscrews are inserted directly into a patient’s bone and provide a secure anchor point from which pressure is exerted to encourage teeth to move to the desired position.

Miniscrews are popular because they are relatively cheap, surgically easy to insert, have multiple placement options, and most importantly, don’t depend on patient compliance and unsightly headgear. However, the success rate of temporary anchorage devices is not particularly high with some screws moving or even pulling out altogether.

Clinical observations suggest a higher failure rate when the screws are put into areas where the compact bone is thicker. Dentist and postgraduate student Dr Melissa Nguyen at the University of Adelaide is studying this at the tissue level by using confocal microscopy in the AMMRF (now Microscopy Australia).

Confocal image showing cracks caused by a 1.5mm diameter temporary anchorage device on 1mm thick compact bovine bone. Microcracks caused by screw insertion are shown in green and by removal, in blue.

Stresses caused by inserting the screws cause microdamage to the bone in the form of microcracks. This causes the bone to remodel itself around the screws. First, specialised cells remove damaged areas before other cells move in to deposit new bone. The initial removal of the damaged bone is the cause of wobbly screws. Dr Nguyen has found a network of cracks emanating from the screw insertion points and her early results appear consistent with the clinical observations.

By understanding how bone thickness and insertion torque lead to microcracks, orthodontists should be able to position screws more reliably and control the insertion forces, thereby reducing miniscrew failures.
